Inomatic

RF Systems

RF Systems (6)

System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 24 VDC or 18 VAC
  • Synchronisation: Opto and wire synch.
  • Receiver: Digital signal processing (DSP)
  • Dimensions (mm):
        Magic 250S — 1540 x 340 x 50
        Magic 250H— 1650 x 340 x 50
  • Weight: 7.5 kg (RX), 7.5 kg (TX) (without panel)
  • Material: Aluminium, ABS and Polypropylene
  • Certifications: CE

System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 24 VDC or 18 VAC
  • Synchronisation: Opto and wire synch.
  • Receiver: Digital signal processing (DSP)
  • Dimensions (mm):
        Magic 250S [black] — 1540 x 340 x 50
        Magic 250H [black] — 1650 x 340 x 50
  • Weight: 9.0 kg (RX), 9.0 kg (TX) (with black panel)
  • Material: Aluminium, ABS and Polypropylene
  • Certifications: CE



System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 20VAC, 1.5A
  • Syncronisation: Mains synchronisation.
  • Receiver: Digital signal processing (DSP)
  • Dimensions: 1540 x 340 x 50mm
  • Weight: 8 kg
  • Material: Aluminium, ABS and Polypropylene
  • Certifications: CE
  •



System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 24 VDC or 18 VAC
  • Synchronisation: Opto and wire synch.
  • Receiver: Digital signal processing (DSP)
  • Dimensions (mm):
        Magic 350S [black] — 1540 x 450 x 50
        Magic 350H [black] — 1650 x 450 x 50
  • Weight: 10.0 kg (RX), 10.0 kg (TX) (with black panel)
  • Material: High Grade Aluminium, ABS and Polypropylene
  • Certifications: CE



System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 24 VDC or 18 VAC
  • Synchronisation: Opto and wire synch.
  • Receiver: Digital signal processing (DSP)
  • Dimensions (mm): 1540 x 340 x 90
  • Weight: 26 kg (per antenna)
  • Material: High Grade Acrylic (25 mm thick), powder coated steel
  • Certifications: CE

System Specifications

  • Frequency: 8.2 MHz
  • Power supply: 24 VDC or 18 VAC
  • Synchronisation: Opto and wire synch.
  • Receiver: Digital signal processing (DSP)
  • Dimensions (mm): 1540 x 340 x 90
  • Weight: 26 kg (per antenna)
  • Material: High Grade Acrylic (25 mm thick),powder coated steel
  • Certifications: CE
